4-channel 100 MHz automotive oscilloscope

Model code: OS100 Manufacturer: Udiag

Device forumAsk questions & share experience

Description

UDIAG OS100 is a 4-channel automotive oscilloscope with 100 MHz bandwidth and up to 1 GSa/s sampling, used with UDIAG's dedicated automotive software.

It captures fast and intermittent electrical faults in ignition systems, sensors, actuators, wiring and CAN/bus networks, with 4 synchronized channels for cross-circuit comparison, ignition tests, sensor actuation tests and multi-vehicle CAN/BUS decoding. UDIAG lists it for petrol vehicles from 1996 and most diesel vehicles from 2008.

Note: this is a measurement tool, not an OBD scanner - it connects to circuits with probes. It is also an optional add-on for UDIAG X-series tablets. No PDF user manual is published on udiagtech.com.

Specifications

Product type	Device with software installed on a computer / tablet / phone
OEM (Original Equipment Manufacturer) product? i	No
For which vehicle	Cars
What programs does it work with?	UDIAG automotive oscilloscope software; UDIAG X-95 Pro / X-60 / X-50 tablets (optional oscilloscope module).
Supported protocols	CAN
Other protocols (details)	CAN/BUS decoding through oscilloscope probes
Menu language	English

Supported functions (1)

Advanced Diagnostics

Oscilloscope / waveform analysis i (4-channel 100 MHz oscilloscope: ignition, sensor and actuator waveforms, CAN/bus decoding. UDIAG lists petrol vehicles from 1996 and most diesel vehicles from 2008.)
