7-inch marine diagnostic tablet for Volvo Penta engines, 12/24 V
Model code: iScan Pro Volvo Penta Manufacturer: OBD Star
OBDSTAR iScan Pro Volvo Penta (Marine) is a 7-inch diagnostic tablet for VOLVO PENTA marine engines. It accepts 24 V DC input.
Functions: read/clear codes, live data (text / waveform / gauge), record and play back data, action tests, settings and coding, plus brand-specific special functions. Support Parameter Programming, Station Configuration, Gain and Stability Calibration, ACP History test, Engine hours programming 1, Engine hours programming 2, Engine hours programming 3, Engine hours programming 4, AdBlue Dosing System tests, Engine Run-up test, Injectors shut off manual 1, Injectors shut off manual 2, Spark shut off test, Fuel pump relay test, Idle Air Control reset test, Throttle activation test, Cylinder Compression mode, Injector control test, Idle speed control test, Spark Fire test, O2 sensor test, Misfire reset test and other special functions. Support D3, D4/D6, D5-D16 GE, D5-D16 VE, D8/D13-1000, D9-D16, Gasoline, QL EST, D12, KAD-300, KAD-44, TAMD-74, TAMD-75, V6 - V8 and other models.
The OBDSTAR app adds diagnostic socket locations and technical bulletins. Wi-Fi one-click updates and remote assistance.
Hardware: Android 5.1.1 tablet, RK3128 quad-core CPU, 7-inch capacitive touchscreen (1024x600), 16 GB storage, 3700 mAh battery, Wi-Fi, micro SD slot up to 32 GB, about 766 g, 243 x 148 x 36 mm.
Function coverage depends on the purchased configuration and software activations - check the coverage list on obdstar.com before buying. OEM dealer software and licences are not included.
| Product type | Device with pre-installed software (standalone) |
|---|---|
| OEM (Original Equipment Manufacturer) product? i | No |
| For which vehicle | Other (agricultural, construction, marine) |
| Price (USD) | $881 – $1,077 |
| Connection with computer / tablet / phone | Wi-Fi |
| Other connection (details) | Connects to the vehicle with the supplied OBD / diagnostic cable |
| Vehicle power supply system | 12V, 24V |
| 24V adapter | No 24V adapter is required |
| 24V software | Separate software does not need to be purchased |
| Frequency of new updates | Online, one-click update over Wi-Fi |
| Menu language | English |
No compatibility data yet.
There's still room here for your shop. If you're a seller and would like to include a link to your shop here, please get in touch with us.
We also accept links to online shops on platforms such as Amazon, eBay, Etsy, AliExpress, Walmart Marketplace, etc.
OBDSTAR Technology Co., Ltd. is a Chinese manufacturer of professional vehicle diagnostic and programming equipment, based in Shenzhen. The company develops key programming (IMMO) tools such as the Keymaster and X300 series, ECU programmers (DC706, ECU Master), airbag crash data reset tools (P50), brand-specific iScan diagnostic tablets for motorcycles and marine engines, the MotoMaster and MarineMaster scanners, and bench test platforms (MT501, MT502, MT203). Its tools are used by locksmiths, automotive electronics specialists and motorcycle and marine workshops worldwide.
